中国腐蚀与防护学报, 2023, 43(4): 755-764 DOI: 10.11902/1005.4537.2023.143

中国腐蚀与防护学会杰出青年成就奖论文专栏

AZ31镁合金表面超疏水耐腐蚀镍基复合涂层

黄志凤, 雍奇文, 房蕊, 谢治辉,

西华师范大学化学化工学院 化学合成与污染控制四川省重点实验室 南充 637002

Superhydrophobic and Corrosion-resistant Nickel-based Composite Coating on Magnesium Alloy

HUANG Zhifeng, YONG Qiwen, FANG Rui, XIE Zhihui,

Chemical Synthesis and Pollution Control Key Laboratory of Sichuan Province, College of Chemistry and Chemical Engineering, China West Normal University, Nanchong 637002, China

通讯作者: 谢治辉，E-mail:zhxie@cwnu.edu.cn，研究方向为镁合金智能防腐涂层的制备与应用

收稿日期: 2023-05-09   修回日期: 2023-06-06

基金资助: 国家自然科学基金.  52271073

Corresponding authors: XIE Zhi-Hui, E-mail:zhxie@cwnu.edu.cn

Received: 2023-05-09   Revised: 2023-06-06

Fund supported: National Natural Science Foundation of China.  52271073

作者简介 About authors

黄志凤，女，1997年生，硕士生

谢治辉，1986年出生，2013年毕业于湖南大学，获博士学位。现就职于西华师范大学，教授。曾于2016年在美国SUNYatBinghamton从事PostdoctoralFellow工作。现任化学合成与污染控制四川省重点实验室副主任。谢治辉博士主要研究方向为镁合金的腐蚀与防护。提出并证明了高电位金属中间层实现光生阴极保护对镁合金的间接防护；设计制备自修复功能金属、有机和无机镁合金防护涂层；获得反应条件与氢状双金属氢氧化物(LDHs)成分、形貌、结构和耐腐蚀性能的关系；调控溶液中螯合剂、镁和铝离子浓度，实现常压中低温镁合金耐腐蚀LDHs膜原位生长。主持国家自科基金(面上/青年)和四川省科技厅等国省级项目近10项。现任国家自然科学基金委、教育部科技发展中心等国省市科研项目和科技奖励评审专家、中国腐蚀与防护学会青工会委员、四川省腐蚀与防护学会常务理事、IJMMM等SCI/EI期刊青年编委和客座编辑、国际腐蚀大会学术委员、CEJ等50余本SCI期刊审稿人。在ACSAMI和表面技术等SCI/EI期刊发表学术论文近40篇，第一发明人获授权发明专利4项。入选中国科协第四届青年人才托举工程，获省科技进步奖、省海外高层次留学人才和省腐蚀与防护学会青年科创人才等荣誉和奖励。2023年获得中国腐蚀与防护学会杰出青年成就奖。

摘要

结合化学沉积和电沉积技术，以动态氢气泡为模板，在AZ31镁合金表面制备了一种超疏水耐腐蚀的镍基复合涂层。涂层形貌、结构、组成、润湿性和腐蚀防护性能的表征结果表明，电沉积溶液中添加ZnO纳米粒子会改变多孔镍层的表面形貌，影响疏水能力。静态水接触角 (WCA) 测试表明，电沉积溶液中ZnO纳米粒子的浓度为5.0 g‧L-1时获得的电沉积镀层经硬脂酸改性后，具有最大的WCA值，达到160.8°±2.8°。相较于裸镁合金，该复合涂层腐蚀电位显著正移，腐蚀电流密度和电荷转移电阻分别降低和提升两个数量级以上，说明复合涂层对镁合金基底具备良好的腐蚀保护能力。

关键词： 镁合金 ; 镍镀层 ; 纳米氧化锌 ; 电沉积 ; 超疏水

Abstract

The superhydrophobic surface has excellent water repellency, which helps to enhance the corrosion protection performance of the coating. In this work, a superhydrophobic and corrosion-resistant nickel-based composite coating was prepared on the surface of AZ31 Mg-alloy by combining chemical deposition and electrodeposition techniques with dynamic hydrogen bubbles as a template. The microscopic morphology, structure, composition, wettability, and corrosion protection performance of the coating were characterized using scanning electron microscopy (SEM), energy spectrometry (EDS), X-ray diffractometer (XRD), Fourier infrared spectroscopy (FTIR), X-ray photoelectron spectroscopy (XPS), optical contact angle meter and electrochemical workstation. It was found that adding ZnO nanoparticles to the electrodeposition bath may change the surface morphology of the porous nickel layer and affect its hydrophobicity. The static water contact angle (WCA) tests revealed that the highest WCA value of 160.8°±2.8° was acquired for the composite coating prepared by electrodeposition in the electrolyte containing ZnO nanoparticles of 5.0 g·L-1 and then modified by stearic acid. Compared to the bare Mg-alloy, the composite coating's corrosion potential was positively shifted by -1.23 V to -0.32 V. The corrosion current density and charge transfer resistance were reduced and increased by more than two orders of magnitude, reaching 8.41 10-7 A·cm-2 and 72.79 kΩ·cm2 respectively, indicating the good corrosion protection ability of the composite coating to the Mg-alloy.

Keywords： Mg-alloy ; Ni-coating ; nano-ZnO ; electrodeposition ; superhydrophobicity

PDF (11570KB) 元数据 多维度评价 相关文章 导出 EndNote| Ris| Bibtex  收藏本文

本文引用格式

黄志凤, 雍奇文, 房蕊, 谢治辉. AZ31镁合金表面超疏水耐腐蚀镍基复合涂层. 中国腐蚀与防护学报[J], 2023, 43(4): 755-764 DOI:10.11902/1005.4537.2023.143

HUANG Zhifeng, YONG Qiwen, FANG Rui, XIE Zhihui. Superhydrophobic and Corrosion-resistant Nickel-based Composite Coating on Magnesium Alloy. Journal of Chinese Society for Corrosion and Protection[J], 2023, 43(4): 755-764 DOI:10.11902/1005.4537.2023.143

镁合金作为一种轻金属，广泛应用于诸多领域[1]。然而，Mg的化学性质较活泼，生成的MgO膜层并不能像铝氧化膜一样致密，难以起到腐蚀防护功能 [2]。镁合金较差的耐蚀性限制了它的应用，有必要采取措施提高其腐蚀防护能力 [3~5]，化学镀镍为常见的表面防护方法 [6]。镍磷合金硬度高、导电性好，能够赋予镁合金良好的腐蚀防护性能 [7, 8]。不过，化学镀镍主要提供物理阻隔作用，当涂层表面存在微孔时，镀层与基底间形成的微电池将加速镁合金的腐蚀 [9]。

研究[10~12]表明，超疏水涂层因其优异的拒水性，有利于阻隔腐蚀介质与材料表面的接触，从而广泛的应用于防水、防污、自清洁和流体减阻等领域。表面结构和表面能是影响材料表面润湿性的主要因素 [13]。目前，主要通过表面结构调控和低表面能物质改性制备超疏水涂层 [14, 15]，电沉积是构建粗糙表面结构的有效途径之一 [16]。以电沉积过程产生的氢气泡作为模板，可得到具有多层次结构的镍镀层 [17]。该方法在燃料电池和电催化领域受到广泛关注，但采用此方法制备超疏水涂层的报道相对较少 [18~20]。另外，研究 [21~23]表明，通过向涂层中添加纳米粒子也有助于涂层表面形成突出，从而构建多层次微纳结构。

前期研究 [24]表明，采用氢气泡模板法电沉积三维结构的多孔镍层经硬脂酸改性后可使涂层获得超疏水表面。为进一步提高涂层的疏水性，我们将在本工作中把ZnO纳米粒子添加到电沉积多孔镍镀液中，考察纳米粒子对复合涂层的润湿性能和腐蚀防护能力的影响。

1 实验方法

实验选用尺寸为30 mm×20 mm×2 mm的AZ31镁合金为基底。基材成分除了Mg外，还包括 (质量分数，%)：Al 3.0、Zn 1.0和Mn 0.2。电沉积时阳极材料为高纯镍片 (≥99.99%)。化学镀镍溶液组成为：六水硫酸镍 (NiSO4‧6H2O，≥98.5%)，柠檬酸 (C6H8O7‧6H2O，≥99.5%)，次亚磷酸钠 (NaH2PO2‧H2O，≥99.0%)，氟化氢铵 (NH4HF2，≥98.0%)，硫脲 (CH4N2S，≥99.0%)。电沉积镍溶液组成为：氯化铵 (NH4Cl，≥99.5%)，六水氯化镍 (NiCl2‧6H2O，≥98.0%)，ZnO纳米粒子 (30±10 nm，≥99.9%)，十二烷基硫酸钠 (SDS，≥98.0%)。所有化学试剂，包括乙醇 (C2H5OH，≥99.7%)，氨水 (NH3‧H2O，25~28%)，磷酸 (≥85.0%，400 mL·L-1) 氢氟酸 (HF，≥40%) 和硬脂酸 (≥99%)。

将镁合金用240、400和1200#的砂纸依次打磨抛光，以去除表面氧化物。用去离子水将镁合金冲洗干净后，浸入丙酮中超声除油10 min。使用含有50.0 g‧L-1 NaOH和10.0 g‧L-1 Na3PO4的碱性溶液在65 °C下脱脂10 min，并用去离子水冲洗后分别置于H3PO4 (85.0%，400 cm3‧L-1) 和HF (≥40%，350 mL‧L-1) 溶液中酸洗和活化。最后，将前处理好的镁合金置于化学镀镍溶液中进行化学沉积。化学镀镍溶液组成 (g‧L-1) 为：C6H8O7‧H2O 5.0、NiSO4‧6H2O 25.0、NaH2PO2‧H2O 25.0、NH4HF2 10.0和CH4N2S 1.0。溶液pH值为5.4~5.8，沉积温度为87 °C，沉积时间为2.0 h。将得到的样品用热风吹干，标记为ENP。

超疏水镍基涂层的制备：以高纯镍片作为阳极，化学镀镍镁合金为阴极，在NiCl2‧6H2O和NH4Cl为主盐，SDS为分散剂的电沉积液 (pH 6.4~7.0) 中进行电沉积，电沉积时电流密度为1.0 A cm-2，沉积时间为60 s。纳米粒子ZnO的浓度为2.0~10.0 g‧L-1。电沉积得到的样品吹干后标记为ENP/NZ-x (x=1, 2, 3, 4, 5)。将新制备的ENP/NZ-x样品在35 °C下置于硬脂酸的乙醇溶液中浸渍24 h，然后用乙醇和蒸馏水依次冲洗干净并吹干，标记为ENP/NZSA-x (x=1, 2, 3, 4, 5)。为了对比，同时制备了未添加ZnO纳米粒子的对照镀层，并将电沉积层和硬脂酸改性后的镀层分别表示为ENP/NZ-0和ENP/NZSA-0。

使用带有能谱仪 (EDS) 的Gemini 500型扫描电子显微镜 (SEM) 观察样品的表面形貌和截面厚度。采用DX-2700BH型X射线衍射仪 (XRD) 对样品进行晶相结构分析。XRD的详细参数如下：Cu靶，扫描速率5º/min，扫描角度范围10°~90°。利用Nicolet 6700型Fourier红外光谱仪 (FTIR) 在波数为400~4000 cm-1范围内对样品表面的化学基团进行表征。利用250Xi型X射线光电子能谱仪 (XPS) 分析样品表面的元素组成、价态和化学键。利用SL200KS光学接触角测量仪测试涂层的静态接触角 (CA)。室温下，将体积为5 μL的水滴滴在水平放置的样品上，使用仪器自带的软件对结果进行拟合。

使用Gamry电化学工作站和常规的三电极体系进行电化学阻抗谱 (EIS) 和Tafel曲线测试。电化学测试在室温下、3.5% (质量分数) NaCl溶液中进行。三电极体系，饱和甘汞电极为参比电极，铂电极为辅助电极，测试样品为工作电极 (暴露面积为1.0 cm2)。测试前，先测量至少1200 s的开路电位-时间 (OCP-t) 曲线，以获得相对稳定的OCP值。EIS测试频率范围为105~10-2 Hz，施加振幅为10 mV的扰动电位。Tafel曲线的电位测试范围为-0.5~0.5 V (vs. OCP)，扫描速率为1 mV·s-1。EIS和Tafel测试数据使用Gamry Analyst软件进行分析。每种样品均重复测试3次以上，以确保测试结果的可靠性及可重复性。

2 结果与讨论

2.1 复合涂层的微观形貌、结构和组成

当电沉积镀液中ZnO纳米粒子的浓度增加到10.0 g‧L-1时，镀层表面出现大量粗糙颗粒，且结合力差，极易脱落。因此，本文主要探讨ZnO纳米粒子添加浓度为2.0和5.0 g‧L-1时所得镀层经硬脂酸改性后复合涂层的结构和性能。两种复合涂层的SEM和相应的元素分布显示 (图1)，纳米粒子的添加对涂层表面形貌有很大影响。纳米ZnO含量的增加获得了更加粗糙的表面结构。当添加2.0 g‧L-1 ZnO纳米颗粒时，镍层表面呈现无数“喇叭花”状凸起结构 (图1a)。根据高倍数SEM图，凸起的“喇叭花”由胞状镍团簇构成，花中间有许多微米级孔隙 (图 1b)。凸起结构将会增大涂层表面粗糙度，而孔隙则可以截留空气，形成“空气”气垫，有利于提升涂层疏水性。当纳米颗粒增加至5.0 g‧L-1时，低倍SEM图像显示 (图1d)，镍层表面有许多大小不一的球状突起，直径最大达到76.2 μm。将直径较大的球状突起放大后看到，其表面还有许多尺寸更小的圆锥形凸起 (图1d插图和图1e)，说明镀层表面形成了 (亚) 微米级的层次结构。由镀层的EDS谱图 (图1b和e的插图以及图1c和f) 可知，镀层表面主要均匀分布Ni、Zn、C和O。其中，Ni和Zn来自于电沉积溶液和ZnO纳米粒子，说明ZnO纳米粒子成功均匀分散于镀层之中，或者Zn与Ni均匀形成合金；C和O来自于长链硬脂酸，表明电沉积镍层表面形成了均匀的有机膜层。两种镀层的EDS分析 (表1) 显示，当电沉积镍溶液中纳米粒子浓度增加时，镀层中Zn含量显著增加。但是，当电沉积溶液中ZnO纳米粒子浓度过高时，镀层表面的突出容易掉落，不利于镀层应用。

图1

新窗口打开| 下载原图ZIP| 生成PPT

图1   ENP/NZSA-2和ENP/NZSA-5复合镀层的SEM形貌和相应的EDS面扫描图

Fig.1   SEM images (a, b, d, e) and corresponding EDS elemental mappings (c, f) for ENP/NZSA-2 (a-c) and ENP/NZSA-5 (d-f) composite coatings. The insets in Fig.1b and e show the photographs and EDS spectra of corresponding coatings


表 1   两种镀层表面不同元素的含量 (mass fraction / %)

Table 1  EDS determined element contents of ENP/NZSA-2 and ENP/NZSA-5 coatings

SampleNiZnCO
ENP/NZSA-281.9813.404.150.46
ENP/NZSA-565.7328.874.990.40

新窗口打开| 下载CSV


为了确定Zn在镀层中的存在形式，测定了不同镀层的XRD谱图 (图2a)。镁合金表面化学沉积的镍磷合金为非晶态结构，在XRD谱中表现为宽泛的衍射峰 (2θ=44.51°)。在32.31°和36.75°处观察到两个尖锐的衍射峰，源自于镁合金基底。当在镍磷合金表面电沉积多孔镍层后，ENP/NZ-0镀层XRD谱图中显示出多个尖锐的衍射峰，表明电沉积镍层为晶态结构。镀层中3个明显的衍射峰，位于衍射角 (2θ) 为44.51°、52.81°和76.34°处，分别对应于Ni的 (111)、(200) 和 (220) 晶面 (JCPDS No：04-0850)[25]。当电沉积溶液中添加ZnO纳米粒子后，上述归属于Ni不同晶面的峰位置没有发生变化，但峰宽增加，说明结晶性受到一定影响。相较于ENP/NZ-0和ENP/NZ-2镀层，ENP/NZ-5镀层在80.29°处出现明显归属于Ni5Zn21合金的衍射峰；在62.97°处观察到微弱的属于ZnO(103) 晶面的衍射峰 (JCPDS No：36-1451) [26]。XRD测试结果表明，当电沉积溶液中纳米粒子增加到一定浓度后，Zn以镍锌合金和ZnO纳米粒子的形式同时存在于电沉积镀层中。不过，由于含量较低，在图谱中的衍射峰强度很弱，在SEM中也很难分辨完整的纳米粒子。尤其是在ENP/NZSA-2镀层的XRD谱中，难以观察到镍锌合金或者ZnO纳米粒子的衍射峰。复合涂层的FTIR如图2b-e所示，位于3418 cm-1的强宽吸收峰源于样品表面吸附H2O分子中羟基 (-OH) 的伸缩振动。两种涂层的FTIR谱均在2850~2980 cm-1范围内出现弱的吸收峰，这主要源于-CH3和-CH2的对称和不对称伸缩振动 [27]。由于金属Ni和Zn的影响，C=O的吸收峰发生偏移。C=O和C-O键的对称和不对称伸缩振动导致的吸收峰分别出现在波数为1639和1454 cm-1处。波数位于1385 cm-1的吸收峰对应于C-H的弯曲振动 [28]。FTIR谱结果进一步证实，硬脂酸层成功附着于电沉积镍层表面。

图2

新窗口打开| 下载原图ZIP| 生成PPT

图2   ENP，ENP/NZ-0，ENP/NZ-2和ENP/NZ-5复合涂层的XRD谱及ENP/NZSA-2和ENP/NZSA-5复合镀层的FT-IR光谱

Fig.2   XRD patterns of ENP, ENP/NZ-0, ENP/NZ-2 and ENP/NZ-5 composite coatings (a), FT-IR spectra of ENP/NZSA-2 and ENP/NZSA-5 composite coatings (b) and their enlarged views in different wavenumber ranges (c-e)


利用高分辨率XPS谱对ENP/NZSA-5镀层进行表征，以进一步分析复合涂层表面元素的组成和化学键信息。XPS全谱 (图3a) 显示复合涂层包含C，O，Ni和Zn。图3b~e分别列出了C，O，Ni和Zn 4种元素的高分辨率XPS谱。C 1s的高分辨率谱 (图3b) 可拟合为3个峰，分别归属于C-C/C-H键 (284.56 eV)、C-O键 (285.05 eV) 和C=O键 (288.60 eV) 的特征峰[29]，再次证明硬脂酸分子成功附着于电沉积镍层表面。O 1s的XPS谱 (图3c) 也可以拟合为3个峰，包括结合能为530.90 eV处的Ni-O键的峰，531.96 eV处源于Ni (OH)2的峰和531.50 eV处源于Zn-O键的峰 [30, 31]。Ni的高分辨率XPS谱 (图3d) 拟合为6个峰，包括结合能为852.30和855.96 eV的Ni 2p3/2特征峰；结合能为869.72和873.70 eV的Ni 2p1/2特征峰；以及Ni 2p3/2 sate和Ni 2p1/2 sate对应的卫星峰，结合能分别为861.70和880.00 eV [31, 32]。Zn 2p的高分辨率XPS谱 (图3f) 有两个峰，结合能为1022.10和1044.96 eV，对应于Zn 2p3/2和Zn 2p1/2，两个峰结合能相差约23.00 eV，说明镍层中存在二价Zn [33, 34]。通过俄歇电子能谱可以进一步确认镍层中同时存在金属态和二价Zn (如图3f)。Zn LMM俄歇电子能谱图中动能为992.78 eV的峰归因于金属态Zn[35]。同时，在动能为987.76 eV处存在另一Auger峰，与金属态Zn的动能差值为5.02 eV，归因于二价Zn(Zn2+)[35, 36]。XPS结果再次证明，Zn在电沉积层中以锌镍合金和ZnO纳米粒子两种存在形式。

图 3

新窗口打开| 下载原图ZIP| 生成PPT

图 3   ENP/NZSA-5涂层的高分辨XPS谱

Fig. 3   High resolution XPS spectra of ENP/NZSA-5 coating: (a) survey spectrum, and fine peaks of (b) C 1s, (c) O 1s, (d) Ni 2p, (e) Zn 2p and (f) Zn LMM


复合涂层横截面SEM (图4a) 表明，涂层外侧横截面呈山峰状起伏，这源于电沉积镍层的多孔结构，导致表面形成许多凹凸起伏的沟壑，极大地增大了涂层表面的粗糙度。根据不同元素的EDS面扫谱图，可以计算化学沉积镍层和电沉积镍层的厚度。由图4a-c可知，复合涂层总厚度为 (76.2±2.0) μm；根据线扫描结果 (图4b) 和P的EDS面扫描谱图 (图4e),化学沉积镍基合金膜层的厚度约为 (60.9±2.0) μm。因为化学沉积镍基合金膜层中含有P，而电沉积层中没有P，所以电沉积层的厚度为涂层总厚度与化学沉积镍层的差值，约为 (15.3±2.0) μm。因Zn同时存在于电沉积层和基底镁合金，因而图 4g的上侧和下侧均能看到明显的富Zn区域。同时，图4g上侧Zn的均匀分布也证实，Zn以合金和纳米粒子形式均匀分散于电沉积层。图4d-f中所示的Mg和C分别来源于镁合金基底和树脂层，与图4a所示复合镀层的形状相匹配。由于树脂中本身含O，而制样过程中镁合金基底和镍基镀层均暴露于水和空气中，所以图4h显示O均匀分布于复合镀层的整个截面。因为硬脂酸膜层很薄，无论是通过线扫描还是面扫描，都难以在EDS谱图中体现。

图4

新窗口打开| 下载原图ZIP| 生成PPT

图4   ENP/NZSA-5样品的SEM截面形貌以及EDS线扫和面扫结果

Fig.4   Cross-sectional morphology (a), line scanning profiles along the direction of the arrow in Fig.4a (b), and corresponding EDS elemental mappings of Ni (c), Mg (d), P (e), C (f), Zn (g) and O (h) for ENP/NZSA-5 coating


2.2 复合涂层的疏水性

镀层的润湿性测试结果显示 (图5)，未掺杂ZnO纳米粒子获得的多孔镍镀层经硬脂酸改性后 (ENP/NZSA-0)，其表面静态水接触角为154.6°±3.7°。相较于ENP/NZSA-0涂层，当向电沉积溶液中添加纳米粒子后，复合涂层的疏水性均明显增加。当添加2.0 g‧L-1纳米ZnO时，ENP/NZSA-2涂层接触角为156.5°±3.5°；当纳米粒子浓度提升至5.0 g‧L-1时，ENP/NZSA-5涂层的接触角增加至160.8°±2.0°。由SEM可知，引入纳米粒子后，涂层表面微观结构发生明显变化，这可能是接触角发生显著变化的主要原因。与ENP/NZSA-2涂层相比，ENP/NZSA-5涂层具有更为突出的 (亚) 微米级层级结构。根据Cassie-Baxter润湿模型 [37]，当水滴接触涂层表面时，微米级圆锥之间的孔隙会形成空气“气穴”，提高涂层的拒水性。一般地，超疏水涂层对日常污染物均具有一定的排斥能力。生活中几种常见溶液 (咖啡、牛奶、3.5% NaCl、去离子水和茶) 在ENP/NZSA-5涂层表面的接触角如图5d和e所示。可以看到，除了牛奶，其它几种溶液在ENP/NZSA-5复合涂层表面的接触角都超过150°，不同液滴在涂层表面都近似球体，说明涂层具有良好的拒液能力。

图5

新窗口打开| 下载原图ZIP| 生成PPT

图5   ENP/NZSA-0，ENP/NZSA-2和ENP/NZSA-5的静态水接触角和ENP/NZSA-5复合镀层表面咖啡、牛奶、3.5% NaCl溶液、茶和去离子水的静态接触角以及相应形貌

Fig.5   Static water contact angles of ENP/NZSA-0 (a), ENP/NZSA-2 (b) and ENP/NZSA-5 (c) coatings, static contact angles (d) and corresponding photographs (e) of ENP/NZSA-5 coating for coffee, milk, 3.5% NaCl, tea and water


图6为ENP/NZSA-2和ENP/NZSA-5复合涂层浸入去离子水和移出过程中的表面形貌。很明显，两种涂层，尤其是ENP/NZSA-5涂层浸入去离子水中部分的表面呈银白色，表面格外明亮 (图6b~d和g~i)。由于空气是光疏介质，水是光密介质，空气被困在涂层粗糙表面的空腔中。当光从水中进入到空气中的入射角高于某临界角，造成全内反射 [38, 39]。全内反射现象的存在进一步说明，水滴在涂层表面的浸润为Cassie-Baxter状态。将复合涂层从去离子水中取出后，样品表面干燥洁净，未残留水膜，说明该涂层具有很好的拒水能力。

图6

新窗口打开| 下载原图ZIP| 生成PPT

图6   NP/NZSA-2和ENP/NZSA-5复合涂层在去离子水中浸入和取出过程的数码照片

Fig.6   Digital photos of ENP/NZSA-2 (a-e) and ENP/NZSA-5 (f-j) composite coatings during immersing into deionized water and taking out


2.3 复合涂层的耐腐蚀性能

EIS和Tafel曲线是评估材料耐腐蚀性能的有效手段 [40]。通过EIS测试可以获得体系的电荷转移和双电层电容等动力学信息。图7为裸镁合金和不同涂层在3.5% NaCl溶液中的EIS谱及相应的等效电路图 (EC)。EIS谱的高频区、中频区和低频区对应样品/溶液界面不同区域的性质。其中，Bode幅频图的低频区、Bode相频图的中高频区和Nyquist图容抗弧的直径均可以反映涂层的耐蚀性能。一般地，涂层的低频阻抗模值越高，容抗弧直径越大，涂层的耐蚀性越好[41]。由图7a可知，相较于镁合金，不同涂层，尤其是ENP/NZSA-5涂层在中低频区域的阻抗值都显著提升。在0.01 Hz处，镁合金的模值仅为0.218 kΩ·cm2，而ENP/NZSA-5复合涂层的模值增加到了89.38 kΩ·cm2，提升了两个数量级。不同涂层的Bode相频图 (图7b) 中，ENP/NZSA-5涂层的最大相位角对应频率最高，表明其具有最优的防腐能力。Nyquist图 (图7c) 同样证实，所有涂层的容抗弧相较于裸镁合金都明显提升，说明几种涂层均具有良好的耐蚀能力。其中，ENP/NZSA-5复合涂层的容抗弧最大，说明其能为镁合金提供最好的防护。

图7

新窗口打开| 下载原图ZIP| 生成PPT

图7   AZ31镁合金以及ENP、ENP/NZSA-2与ENP/NZSA-5涂层在3.5%NaCl溶液中的电化学阻抗谱及其等效电路图

Fig.7   Impedance module (a), phase angle (b), Nyquist (c) plots and corresponding logRct and log|Z| f=0.01 Hz (d) for bare magnesium alloy, ENP, ENP/NZSA-2 and ENP/NZSA-5 coatings in 3.5% NaCl solution, and equivalent circuit diagrams for AZ31 Mg-alloy (e) and various coatings (f)


使用EC和Gamry Analyst软件对EIS拟合分析，可以得到量化的电化学参数 (表2)。图7e为用于裸镁合金拟合的EC图，包括Rs、Rct、CPE、L以及RL，分别表示溶液电阻、电荷转移电阻、常相位角元件、电感及感抗。除了上述部分元件，图7f所示的EC图用于不同涂层的拟合，其还包含Rc和Qc，分别表示膜层电阻和电容。由表2可知，所有涂层的Rct值均显著高于裸镁合金。ENP/NZSA-5复合涂层的Rc和Rct值最大，后者达到72.79 kΩ·cm2，约为裸镁合金的227倍，ENP涂层的5倍。总之，复合涂层展现了良好的腐蚀防护能力，能有效防止镁合金腐蚀。

表2   AZ31镁合金以及ENP、ENP/NZSA-2与ENP/NZSA-5涂层的EIS拟合值

Table 2  Electrochemical parameters obtained by fitting the EIS spectra of AZ31 Mg-alloy, and ENP, ENP/NZSA-2 and ENP/NZSA-5 coatings

Sample|Z|ƒ=0.01 HzkΩ·cm2RsΩ·cm2CPEc10-6 S·s n ·cm-2RckΩ·cm2CPEdl10-7 S·s n ·cm-2RctkΩ·cm2χ210-3
Mg-alloy0. 21832.04//102.800.321.53
ENP13.5426.2636.229.6578.4114.851.85
ENP/NZSA-239.8125.393.4314.7776.4035.053.87
ENP/NZSA-589.3826.401.0224.5667.3172.794.90

新窗口打开| 下载CSV


图8为常温下镁合金和不同涂层在3.5% NaCl溶液中的Tafel曲线以及相应的Ecorr和Icorr值。由图8a可知，与裸镁合金相比，沉积涂层后样品的Ecorr明显正移，Icorr显著降低。根据拟合得到的Tafel参数 (表3)，镁合金的Ecorr为-1.55 V，Icorr为7.37×10-5 A·cm-2。化学镀镍后Ecorr正移至-0.61 V，Icorr降低至7.32×10-6 A·cm-2。相较于单一ENP镀镍层，ENP/NZSA-2和ENP/NZSA-5的Ecorr进一步正移至-0.32 V，Icorr降低至8.41×10-7 A·cm-2。Tafel曲线结果同样证实，复合涂层明显提高了对镁合金的保护能力。图8b更直观反映了不同样品间Ecorr和Icorr的差异。显然，不同涂层的腐蚀防护能力按照以下顺序依次降低：ENP/NZSA-5>ENP/NZSA-2>ENP涂层>裸镁合金，与EIS结果一致。

图8

新窗口打开| 下载原图ZIP| 生成PPT

图8   AZ31镁合金和不同涂层在3.5%NaCl溶液中的Tafel曲线及相应的Ecorr和Icorr值

Fig.8   Tafel curves (a) and corresponding Ecorr and Icorr (b) of AZ31 Mg-alloy and various coatings in 3.5% NaCl solution


表3   AZ31镁合金和不同涂层的Tafel参数拟合值

Table 3  Fitting data of Tafel parameters of AZ31 Mg-alloy and various coatings

Sampleβa / mV·dec-1-βc / mV·dec-1Ecorr / VIcorr / A·cm-2
Mg-alloy/186.30-1.557.37×10-5
ENP410.90137.30-0.617.32×10-6
ENP/NZSA-2320.10154.60-0.492.04×10-6
ENP/NZSA-5/149.00-0.328.41×10-7

新窗口打开| 下载CSV


3 结论

(1) 结合化学沉积、电沉积和动态氢气泡模板法，并利用硬脂酸改性，可以在镁合金表面获得超疏水耐腐蚀的镍基复合涂层。

(2) 电沉积镍电解质中添加ZnO纳米粒子后，Zn会以镍锌合金和纳米颗粒两种形式存在于多孔镍层中。

(3) 当电沉积溶液中ZnO纳米粒子浓度为5.0 g/L时，具有最佳的耐蚀性能和拒液能力。

(4) 与裸镁合金相比，最优复合涂层的腐蚀电位明显正移，腐蚀电流密度和电荷转移电阻分别显著降低和提升。同时，复合涂层对生活中几种常见的溶液均表现出优异的排斥能力，具有良好的超疏水性能。
